SHELLY
LORAADDON2PACK
Shelly LoRa Add-on 2-pack
Product code:
LORAADDON2PACK
Description
The ultimate solution for long-range, reliable communication. Whether you're automating street lighting, managing remote facilities, or optimizing smart agriculture, this compact yet powerful device extends connectivity where traditional solutions fall short. Built with LoRa technology, it ensures secure, efficient, and uninterrupted performance – even in the most challenging environments
Note: To connect your Shelly LoRa Add-on, you will need at least two devices – one to transmit the signal and one to receive it. Please ensure you have both for the initial setup.
Main features
- Communicate up to 5 km with ease, thanks to the external antenna.
- Seamlessly integrates with Shelly Gen3 and Gen4 devices for extended communication.
- Built to perform even in obstructed or hard-to-reach areas.
- Built-in AES-CCM encryption with support for unicast, multicast, and broadcast addressing via the Shelly Protocol.
- Supports EU868, US915, and BR915-928 regions, with AU915-928 support coming soon.
- Supports custom scripts to address specific use cases.
- Supports low power mode for EU868, enabling continuous communication without duty cycle limitations.
Technical Details
Specification
Specifications
| Quantity | Value |
|---|---|
| Physical | |
| Size (HxWxD): | 40x42x11 mm / 1.58x1.66x0.44 inch |
| Weight: | 10 g / 0.4 oz |
| Mounting: | Via the Shelly proprietary serial interface to connect to a Shelly compatible device |
| Shell material: | Plastic |
| Shell color: | Black |
| Environmental | |
| Ambient working temperature: | -20 °C to 40 °C / -5 °F to 105 °F |
| Max. altitude: | 2000 m / 6562 ft |
| Electrical | |
| Power supply: | 3.3 V (from compatible Shelly device) |
| Power consumption: | < 150 mW |
| Compatible devices: | Shelly Gen3 Devices:
|
| Range: | Up to 5 000 m / 16 400 ft |
