PMG Signature Phono Preamplifier Silver
Description
- Class A Balanced Analog Output Stage
- Zero Feedback Folded Cascodes
- Fixed And Variable Loading
- Hybrid Design
- Balanced Xlr Output
- 70Db Ultra Low Noise Gain .15Mv Cartridges
- 2X Inputs For 2X Tonearms
- Transimpedance Input
- High-Current Oversized Analog Power Supply
- Discrete Fet Design
- No Capacitors In Output Signal Path
- Class 'A' Analog Circuitry
- Diamond Buffers Throughout
Technical Details
Specification
Weight: 30 lbs / 13.6 kg
Dimensions: 14 3/4” x 17 1/2” x 4 3/8” (with feet). 375 mm x 445 mm x 112 mm (with feet)
Voltage Options (Factory set only): Auto Voltage: 120VAC or 230VAC 50 or 60Hz
Fuses: 120V: T250V-1.6AH (1.6A Slow Blow). 230V: T250V-1AH (1A Slow Blow)
Accessories Included: US (NEMA 5-15P) (100V/120V versions). Schuko (CEE7/7) (230V version). UK (BS1363) (230V version). Remote Control
Audio Inputs: MM or MC: XLR or RCA. TZ: XLR or RCA
Audio Outputs: RCA (Unbalanced) 1 Stereo Pair. XLR (Balanced) 1 Stereo Pair.
DC Trigger: Input: 3.5mm (2) 5-15VDC
Performance: All measurements are with both channels operating, gain set to low, and balanced outputs. Input frequency is 1kHz.
Input Loading: 47K, 1K, 470, 320, 200, 140, 100, 67, 40, 30, 16, 12
Properties
Properties
| Technology | AV |
| Finish | Silver |
