Shelly Pro RGBWW PM

Description

Shelly Pro RGBWW PM (the Device) is a DIN-rail mountable, five-channel smart light controller. It has 5 inputs (button, switch or analog), and five outputs. The Device is commonly used with LED strips. It supports 4 profiles - RGB and CCT (default), CCT x 2, RGB and lights x 2 and Lights x 5. In Lights x 5 profile, 5 different led strips (groups of lights) can be controlled independently. Power measurement functionality allows real time track of the voltage, current and power consumption. The Device can work standalone in a local Wi-Fi network or it can also be operated through cloud home automation services. It can be accessed, controlled, and monitored remotely from any place where the User has internet connectivity, as long as it is connected to a Wi-Fi router and the Internet. Shelly Pro RGBWW PM has an embedded Web Interface which can be used to monitor and control the Device, as well as adjust its settings.

Main features

• DIN rail mountable
• Supports multiple profiles: Supports RGB and CCT (default profile), CCT x 2, RGB and lights x 2 and Lights x 5
• Power measurement: Precise monitoring of energy consumption.
• Bluetooth: The Device complies the Bluetooth standard and can connect with other Bluetooth devices to exchange data in short range.
• BLE Gateway: Facilitates communication between BLE and Wi-Fi-enabled devices.
• Wi-Fi: The Device can connect to a wireless network.
• Wi-Fi Range extender: Retransmits the Wi-Fi signal and extends its reach.
• Ethernet:
• Scripting: Allows creating automation scenarios through scripts.
• Basic Schedules: Supports weekly schedules and routines, including setting of brightness, transition duration, and flip value of the dimming signal.
• Аdvanced Schedules: Supports detailed schedules and routines throughout the year with a broad range of time adjustments from seconds to months, including setting of brightness, transition duration, and flip value of the dimming signal.
• Auto on/off timers: Enables auto on/off timer setting.
• Local actions: Allows creating automation scenarios within the local Wi-Fi network, including setting of brightness, transition duration, and flip value of the dimming signal.
• Webhooks: Supports automation through lightweight, event-driven communication with other devices.
• Compatibility: Highly compatible with 3rd Party home automation systems.
• No need for hub: Ready for use locally or remotely via Shelly Smart Control or 3rd Party systems.
• Activity log: Stores detailed history of events.
• KVS (Key-value storage): KVS service provides a basic persistent storage of key-value pairs.
• Safety: Оver current/voltage/power protections
• Dynamic components: A special set of components that do not exist in the device initially and are created dynamically by the user.
• Independent control for each output (channel) in Lights x 5 profile: Provides separate control for each output for maximum flexibility.
• Hight frequency mode: The users can choose to increase PWM frequency to 22kHz to reduce the acoustic noise from the DC driver. This might cause non-precise colors in profiles with RGB lights when running at low brightness. Default frequency: 833 Hz.
• Night Mode: Enables to set a specific brightness of input lights during nighttime.
  • When the night mode time is set, the brightness is always set to the target night mode brightness, no matter the current brightness or the min brightness on power on
  • Default values: 50% brightness, RGB (255,255,255), 4600K (what’s applicable). Option to change brightness or color/color temperature only (to keep current color/color temperature or brightness).
• Switch/Button/Analog input mode: Allows flexible input control through switches, buttons or potentiometers (10kΩ analog input)
  • CCT x 2 - Input(0) and Input(1) control CCT(0) (no temperature dimming), Input(2) and Input(3) control CCT(1), Input(4) is detached
  • RGB and CCT - Input(0) and Input(1) control RGB, Input(2) and Input(3) control CCT. Input(4) is detached
  • RGB and lights x 2 - Input(0) controls RGB, Input (2) controls Light(0), Input (3) controls Light(1), Input(1) and Input(4) are detached
  • Lights x 5 - Input(x) controls Light(x)
  • One button dimming control - all profiles
  • Dual button dimming control - dimming up/down for brightness only (color temperature cannot be controlled (changed) through buttons).
• Transition duration: Controls the time between change from current brightness level to desired brightness level in request (both for color and white). Applied on color temperature property also. No separate transition for color temperature. Default transition not applicable if input mode is “Analog”, in this case only the explicit (custom) transition is applied for schedules and actions.
• Minimum brightness on toggle On: Brightness level (in percent) applied when there is a toggle On and current brightness is lower than 'Min brightness on toggle'. Default is 3% (for all profiles). Applied on RGB, CCT and Light component.
• Min/Max brightness: Reframes the range of the dimming signal to get more precise brightness control on the output. Applied on brightness property only.
• Min/Max color temperature: Provides support for different CCT LED strips by remapping output color temperature min/max range to the specified values. Max value needs to be greater than min value. Min value: 1000-9999 K, max value: 1001-10000 K. Default values: min: 2700 K, max: 6500 K
• Button fade rate: Controls how quickly the output brightness changes while holding the button(s).
• Button presets: Brightness and color (or color temperature) to be applied on double-click. Default values: 100% brightness, RGB (255, 255, 255), 4600 K. Option to change brightness or color/color temperature only (to keep current color/color temperature or brightness).
