THEBEN
DU 1 DALI KNX
Flush-mounted 1-way DALI actuator, KNX TP, Data Secure
Product code:
4942580
Flush-mounted 1-way DALI actuator, KNX TP, Data Secure. DALI-2 certified. Interface between the DALI and the KNX bus system
Description
- Flush-mounted 1-way DALI actuator, KNX TP, Data Secure.
- DALI-2 certified.
- Interface between the DALI and the KNX bus system.
- Simple commissioning of up to 30 ECGs in broadcast mode.
- Control of RGB, RGBW, Tunable White or conventional luminaires.
- DT-8 luminaire support.
- Easy replacement of ECGs in the event of a fault.
- Universal mounting thanks to the compact housing.
- 2 binary inputs for potential-free contacts such as pushbuttons, switches, window contacts, temperature sensor (input I2).
- The binary input I1 is assigned to the output ex works (function test and operation even without programming).
Technical Details
Specification
Operating voltage KNX: Bus voltage, ≤5 mA
Operating voltage: 230 V AC 50 – 60 Hz
Frequency: 50 – 60 Hz
Stand-by consumption: ±0.35 W
Installation type: Flush-mounted
Type of connection: Terminal screws | Bus connection: KNX bus terminal
Number of channels: 1
Type: Base module
Ambient temperature: -5°C ... 45°C
Type of protection: IP 20
Protection class: II
Properties
Properties
| Technology | KNX |
| KNX Secure | Yes |
